    1200tpd Limestone Rotary Kiln System

    Ask Lasest Price
    Brand Name : Pengfei
    Model Number : Φ2.8---Φ6.0
    Certification : CE,ISO
    Price : USD400000-USD3000000
    Payment Terms : L/C,T/T
    Supply Ability : 1 set per 180 days
    Delivery Time : 180 days
    • Product Details
    • Company Profile

    1200tpd Limestone Rotary Kiln System

    WELCOME TO JIANGSU PENGFEI GROUP CO.,LTD


    1200tpd Limestone Rotary Kiln System


    We can design as per your requirements if you provide us the capacity or the size, we will calculate and choose one right type for you. The rotary kiln must be in good quality,because the rotary kiln shall be running for 24 hours. And once stop, it need three days to restart, time is money, So please choose Pengfei, because we have long history and much more experience on manufacturing and improving the rotary kiln.

    From two piers to four piers.Now our rotary kiln are the leaders for rotary kiln in cement plant with capacity from 300tpd,700tpd,800tpd,1000tpd,1200tpd,1500tpd,2000tpd,2500tpd,3000tpd,3500tpd,4000tpd,5000tpd, 8000tpd ,lime plant capacity from 300tpd to 1200tpd.300tpd,400tpd,600tpd,800tpd,1000tpd,1200tpd.Nickel ore plant from 50000tons 150000tons.our such rotary kiln with advanced technology and high automation level can increase the running rate 3-5%,production has been raised by 5-10%, and heat consumption has been reduced 15% down. Till now we have sold to more than 200 hundred clients in the domestic clients in such filed and more than 100 hundred clients in foreign countries. we also cooperate European countries for the rotary kiln manufacturing.


    Technical performance of Φ2.5×45m rotary kiln


    No.ItemTechnical data and performance
    1SizeΦ2.5×45m
    2Capacitykg/h
    3QualityChina national standard
    4Slope3.5%
    5Shell speed0.4~ 1.2r/min
    6Auxiliary speed0.2rpm
    7Supporting piers3 piers
    8Sealing at kiln outletSpring steel plate
    9Cooling way of kiln outletAir cooling
    10Sealing at kiln inletSpring steel plate
    11Drive typeSingle drive
    12Thrust roller typeHydraulic thrust roller
    13Main motor typeYVF2-280M-6,P=55KW, Rated speed 1000r/min
    14Main gear boxZSY315-40
    15Auxiliary motor typeY160M-6,7.5KW,Rated speed 970r/min
    16Auxiliary gear boxZL35-7,speed ratio14
    17Inlet temperature of medium1000~1100℃
    18Outlet temperature of medium350~400℃
    19Equipment weight158t
    20Running rate98%

    Company workshop


    Company Branches

    Main workshop

    west branch

    Company inspection center

    After sales service

    Service:

    1. We offer perfect after-sales services to our customers throughout the world. Our skilled and experienced after-sales service staff can stay in your factory for equipment assembly and debugging.

    2. We also have emergency after-sales services to solve various operation problems and equipment faults existing in the production processes. We will send our technicians to your production sites to solve your problems.

    3. We will strictly observe the set delivery time, and will never make excuses to delay the delivery time.
